python绘制饼状图qml显示示例4

运行需要安装pyside6。

pip install pyside6 -i https://pypi.douban.com/simple/

创建main.py文件，python代码注释如下：

import osfrom pathlib import Pathimport sysfrom PySide6.QtCore import Property, QUrlfrom PySide6.QtGui import QGuiApplication, QPen, QPainter, QColorfrom PySide6.QtQml import qmlRegisterTypefrom PySide6.QtQuick import QQuickPaintedItem, QQuickView, QQuickItemclass PieSlice (QQuickPaintedItem):    def __init__(self, parent=None):        QQuickPaintedItem.__init__(self, parent)        self._color = QColor()    @Property(QColor)    def color(self):        return self._color    @color.setter    def color(self, value):        self._color = value    def paint(self, painter):        pen = QPen(self._color, 2)        painter.setPen(pen)        painter.setRenderHints(QPainter.Antialiasing, True)        painter.drawPie(self.boundingRect().adjusted(1, 1, -1, -1), 90 * 16, 290 * 16)class PieChart (QQuickItem):    def __init__(self, parent=None):        QQuickItem.__init__(self, parent)        self._name = None        self._pieSlice = None    @Property(str)    def name(self):        return self._name    @name.setter    def name(self, value):        self._name = value    @Property(PieSlice)    def pieSlice(self):        return self._pieSlice    @pieSlice.setter    def pieSlice(self, value):        self._pieSlice = value        self._pieSlice.setParentItem(self)if __name__ == '__main__':    app = QGuiApplication(sys.argv)    qmlRegisterType(PieChart, 'Charts', 1, 0, 'PieChart')#注册类    qmlRegisterType(PieSlice, "Charts", 1, 0, "PieSlice")    view = QQuickView()    view.setResizeMode(QQuickView.SizeRootObjectToView)    qml_file = os.fspath(Path(__file__).resolve().parent / 'app.qml')    view.setSource(QUrl.fromLocalFile(qml_file))    if view.status() == QQuickView.Error:        sys.exit(-1)    view.show()    res = app.exec()    del view    sys.exit(res)

创建app.qml界面文件，代码注释如下：

import Chartsimport QtQuickItem {    width: 300; height: 200    PieChart {        id: chart        anchors.centerIn: parent        width: 100; height: 100        pieSlice: PieSlice {            anchors.fill: parent            color: "blue"        }    }    Text {        id: t1        anchors {            bottom: parent.bottom;            horizontalCenter: parent.horizontalCenter;            bottomMargin: 20        }        text: "当前颜色" + chart.pieSlice.color    }    Component.onCompleted: console.log("The pie is colored " + chart.pieSlice.color);}
